Rio Pro Xtended labeling printer

Print extra-long cards for ticketing, accreditation and product labeling.w

Rio pro xtended large format plastic card printer

Card printer options:

Card encoding options:

Printer model number:

The Rio Pro Xtended is ideal for food labaling

Xtend your card printing capability

The specially modified Rio Pro Xtended, built on the reliable Rio Pro print engine, enables the high quality printing of cards up to 140mm long. Long format cards provide more design options and superior visibility and are ideal for sport and music events. The Rio Pro Xtended is also widely used for ISEGA approved labelling of food produce.


Vibrant colours in every printPrint large formats card for loyalty and membership schemes

The Magicard Rio Pro Xtended uses colour profiles determined by International Colour Consortium (ICC) to ensure that the image you see on screen is the one you hold in your hands after it is printed. The easy-to-use driver interface also enables you to fine-tune colours to get an exact match for your corporate identity.

3 years UCP icon

Backed by the industry’s best 3 year warranty*

Magicard Rio Pro Xtended with UltraCoverPlus – is our promise to keep you printing.

The reliability of our well-established print engine enables us to offer you a comprehensive 3 year warranty with full telephone and online support. This includes a free replacement for any printhead damaged over the lifetime of the warranty. In the unlikely event of a field failure, we will send you a replacement loan printer to you whilst we repair your existing device.

*Available in the EU, North America and other selected territories.
Elsewhere 1 year minimum limited depot warranty.

Rio Pro Xtended specifications


  • Printing performance

    >150 full colour cards
    per hour

  • Card capacity

    100 cards input
    70 cards output

  • Warranty*

    3 year UltraCoverPlus
    with hot swap printer

  • Visual security

    Standard or custom
    HoloKote® watermark

  • Operating system

    Windows and Mac OS


Printer Details
Print technology Long format 300dpi colour and monochrome dye sublimation
Feed system Manual and hopper fed
Card capacity 100 input / 70 output
Single-sided printing
Warranty Details
3 years UltraCoverPlus Includes telephone support, full printhead coverage and loaner service. *Available in North America, EU and other selected territories. Elsewhere a minimum of 1 year limited depot warranty
Accepted card dimensions Details
Standard card sizes ISO CR80 85.6mm x 54mm / 3.38″ x 2.12″
ISO CR79 83.9mm x 51mm
Extended card sizes Colour print up to 110 x 54mm / 4.33″ x 2.12″
Monochrome print up to 140 x 54mm
Card thickness 0.51mm to 1.02mm / 20mil to 40mil
Physical specifications Details
Printer weight 4.95kg / 10.9lbs
Printer size Length: 612mm / 24.1″ Width: 220mm / 8.6″ Height: 250mm / 9.8″
Environmental operating range Sheltered office environment 10°C to 30°C
Power source External power supply 100-240V 50-60Hz autoranging.
Connectivity and drivers Details
Operating systems Windows XP, Vista, 7, 8.1, 10 (32 and 64bit)
Windows server 2003 R2 SP2, 2008, 2012, 2016
GNU/Linux and Mac OS X 10.9.0 onwards
USB connection USB rev1.1 and USB 2.0
Ethernet connection As standard
Printer variants Details Product code
Rio Pro Xtended 54 Xtended printer for 54mm card width 3652-0008
Rio Pro Xtended 50 Xtended printer for 50mm card width 3652-0009

Rio Pro Xtended solutions

  • Events

    The Rio Pro Xtended’s long format cards provide more design options and superior visibility and as such are widely used for security badges at sports and music events

    Read moreIndustry

  • Labelling

    Hygienic, clear to read and versatile, wipe-clean cards up to 140mm (5.5”) long can be printed locally by the Rio Pro Xtended for the product labelling of foodstuffs.

    Read moreApplication

Rio Pro Xtended consumables

  Product code Details Capacity
Colour dye film MA100YMCKO 5 panel colour dye film – YMCKO 100 images
MA300YMCKO 5 panel colour dye film – YMCKO 300 images
Monochrome dye film MA600KO 2 panel black monochrome dye film + overcoat 600 images
MA1000K-Black Black monochrome dye film 1000 images
MA1000K-White White monochrome dye film 1000 images
MA1000K-Blue Blue monochrome dye film 1000 images
MA1000K-Green Green monochrome dye film 1000 images
MA1000K-Red Red monochrome dye film 1000 images
MA1000K-Gold Gold monochrome dye film 1000 images
MA1000K-Silver Silver monochrome dye film 1000 images
Cleaning kits 3633-0053 Rio Pro cleaning kit 10 cards, 1 pen
3633-0054 Rio Pro roller cleaning kit 5 sleeves, 1 roller bar
Xtended cards M9007-432 Xtended cards 110 x 54mm 1000 blank
M9007-433 Xtended cards 140 x 54mm 1000 blank
